Electromagnetic Foil Industrial Aluminum Foil For Power Battery 0.015mm

Advantages

1.The inhibition of cell polarization, reduce the heating effect and improve the rate performance;

2.Reduce the battery internal resistance, and decrease the circulation process of dynamic resistance increase;

3.Improve the consistency, increase the battery cycle life;

4.Improve the adhesion of and active materials, reduce the pole piece manufacturing cost;

5.Protect collection of fluid from the electrolyte corrosion;

6.Improve lithium iron phosphate, lithium titanate materials processing performance.

Surface Qulity

Be free from Oil Stain, Dent, Inclusion, Scratches, Stain, Oxide Dicoloration, Breaks, Corrosion, Roll Marks,

Dirt Streaks and other defect which will interfere with use.

Production standard

Chemical Composite: GB/T 3190-2008, JIS, EN, ASTM

Mechanical Property: GB/T 3880-2006, JIS, EN, ASTM

Certificate

ROHS, SGS, FDA, ISO9001:2008, ISO14001:2004, GB/T 28001-2001, FORM A/E or CO, Mill Test Report.

Technical parameters

Usage

Mainly use for making battery.Battery aluminum foil used as a collector of lithium ion batteries.Usually, used as

the positive collector body in lithium-ion battery industry.

Coating thickness (Double side) A: 4~6um B: 2~3um

Conductive coating:

Using functional coatings for surface treatment of battery conductive substrate is a breakthrough of technical

innovation, coated carbon foil/copper foil is to spread good nano conductive graphite and carbon coated

particles, fine and uniform coating on aluminum foil/copper foil.Static electrical conductivity, it can provide an

excellent collection of active material micro electric current, which can greatly reduce the positive/negative

material and collector, the contact resistance between the and can improve the adhesive ability between the

two, can reduce the use amount of binder, which creates an significantly improve the overall performance of

the battery.Can be divided into water based coating (water system) and oil (organic solvent system) two types

Main Product Form

Luoyang Tailian New Materials Co., Ltd.

                More than 60000 square meters ground area with initial investment 0.28 billion RMB (up to 0.8 billion as planned), Luoyang Tailian New Materials Co., Ltd. is established in 2016 and located in Weiliu Road, East Industry Cluster of Yichuan County, Luoyang City, Henan Province, specializing in manufacturing of commercial standard aluminium coil, aluminium sheet and further downstream aluminium foil for electrolytic capacitor (etched foil and formed foil), aluminium foil tape, honeycomb aluminium foil, decoration foil and aluminium PS plate.

                 Currently our plant consists of two aluminium foil production lines of φ280*φ850*2000mm, a cold-rolling production line (1850mm width), four 60-ton vacuum annealing furnaces, two 60-ton energy saving annealing furnaces, two vertical slitting machines, three horizontal slitting machines (1650mm width), ten etched foil and formed foil production lines, two production lines of coated foil for super electrolytic capacitor, standard laboratory and other supporting facilities.

                 We are equipped with advanced equipment, complete facilities, experienced managing, researching and developing team. We have got multiple national patents for cathode aluminium foil production. Our products are widely accepted by customers in the market, as good as Japanese and South Korean products.

                 In present marketing situation we will keep dedicated to product quality and marketing ethics to develop along with our customers and do the best to bring our products and service to a leading level in the industry.
