Decorative Colored Printed Bopp Aluminum Foil & Laser Foil For Wrapping Packaging

1.Introduction

Color coated aluminum coil is aluminum coil after cleaning, coating, and baking. Surface of aluminum coil can

be painted to any color.The color-coated aluminum coil and aluminum sheet coils mainly come from

Southwest Aluminum, Nanping, Chinalco, Ruimin, etc. which are the best raw materials suppliers domestically.

Our coating paints are mainly from American

2 . Application

As per types of surface coating of paint, color coated aluminum coils can be divided into polyester (PE) coated

aluminum coil, fluorocarbon (PVDF) coating aluminum coil and Epoxy coated aluminum coil.

According to the thickness of the coating, it can be divided into single-coated aluminum coil (4-20 microns);

double-coated aluminum coil (25 to 28 micron) and triply-coated aluminum coil (35-38 micron).

TAILIAN Color coated aluminum coil is widely used in the roofing and cladding system, ceiling system, curtain

wall plate, shutter, gutter, composite panel, can, home appliances board and embossed aluminum coil.

3 .Testing data

Item	Test Item	Performance indicators for PE	Performance indicators for PVDF
1	Color Difference	ΔE≤2.0	ΔE≤1.5
2	Gloss Difference	≤5	≤5
3	Coating Thickness	Two layers Min 23μm Three layers Min 30μm	Two layers Min 25μm Three layers Min 34μm
4	Pencil Hardness	≥HB	HB
5	T-bend	≤3T	≤3T
6	Adhesion	Grade 0	Grade 0
7	Impact	≥20kg.cm	≥50kg.cm
8	Boiling water Resistance	4h No change	4h No change
9	Solvent Resistance	200 times no break	200 times no break
10	Acidity Resistance	5%HCL 24hrs No change	5%HCL 24hrs No change
11	Alkali Resistance	5%NaOH 24hrs No change color E≤2.0	5%NaOH 24hrs No change color E≤2.0
12	Oil Resistance	20#oil 24hrs No change	20#oil 24hrs No change
13	Salt Spray Resistance	720hrs ≤Grade 1e	720hrs ≤Grade 1e
14	Abrasion resistance	≥5L/μm	≥5L/μm
15	Dirt Resistance	≤5%	≤5%
